AWS public/private network architecture
by James Armes (they/them)
So you’ve got your shiny new AWS account and now you want to start launching some resources. Your account comes with a default VPC so you can just launch your resources in there and you’re good to go right? Right‽
If you’ve ever started poking around with a brand new account, then you know it’s not that easy. You may eventually throw an Elastic IP on an EC2 instance so now you can connect to it and it can connect to the Internet. Now, of course, you’ve just opened up your network.
Introducing public/private network architecture
You can separate systems that shouldn’t be available from the public Internet from systems that can access it by using both public and private subnets. Your private systems can still access the Internet if needed.
Some benefits of this architecture are:
- Public subnets allow resources to be directly accessible from the Internet
- Private subnets preventing resources from being directly accessible from the Internet
- A NAT Gateway can allow resources in a private subnet to connect to the Internet or other AWS services
- Additional subnet types can be added for additional security or connectivity
Great! How do I do it?
You can set up a simple public/private network architecture on AWS with a VPC that has enough IP addresses to split across two or more availability zones (I recommend three!). Create two subnets in each availability zone, one each for public and private resources. When determining your CIDR ranges, consider what resources you need to be available directly from the Internet; this will determine the size of your public subnet. Your public subnet will likely be much smaller than your private one in terms of address space.
Public subnets
Public subnets will need an Internet Gateway to establish Internet connectivity. You can use the main route table for all subnets, or a separate route table can be created for each. The routing table should contain the following two routes at a minimum:
| Destination | Target |
|---|---|
| 0.0.0.0/0 | Internet Gateway for the VPC |
| VPC CIDR | local |
If you’re using the default routing table, it should be configured like this already.
Private subnets
If your private resources don’t need to access the Internet, then they can share a single route table with the following configuration:
| Destination | Target |
|---|---|
| VPC CIDR | local |
If your private resources do need access to the Internet, you’ll need to add one or more NAT Gateways in the public subnets. While each of your subnets can use a single gateway, and therefore route table, this can lead to a single point of failure.
A single NAT gateway may be fine for a non-production environment, but for high availability you should have one per availability zone. This ensures that if an availability zone goes down, your resources in the over availability zone(s) will still operate. Multiple gateways will require one route table for each private subnet.
Regardless of the number of route tables you end up with, they will each need the following routes:
| Destination | Target |
|---|---|
| 0.0.0.0/0 | NAT Gateway |
| VPC CIDR | local |
Make sure to associate each route table with the appropriate subnet(s).
VPC Endpoints
When you try to connect to systems outside your VPC from the private subnet, your traffic will flow through the NAT Gateway. This includes connecting to AWS services such as S3 or SSM (Systems Manager). Connecting to these services and sending your data over the Internet introduces security risks. These risks can be avoided with VPC Endpoints.
VPC Endpoints allow resources in your VPC to access services over PriavteLink. When you create an endpoint for an AWS service, DNS requests will resolve to the private IP addresses. Therefore, there’s no need to configure any routes to use the VPC endpoint.
If you plan on using SSM to manage your instances, you wil need to configure VPC endpoints. At a minimum, you will need an endpoint for com.amazonaws.region.ssm. For some features, like Session Manager, you will also need endpoints for com.amazonaws.region.ec2messages and com.amazonaws.region.ssmmessages.
Putting it into code
There are many infrastructure as code (IaC) options that can support implementing this architecture, including Amazon’s own CloudFormation and Cloud Development Kit (CDK). Here, we’ll be using Terraform, a popular open source IaC tool.
We could create each resource individually using the AWS provider.
However, Amazon has published a number of modules to help create
common sets of resources. This includes vpc anc vpc_endpoints. We can use these
in our main.tf to setup everything we need.
module "vpc" {
source = "terraform-aws-modules/vpc/aws"
version = "3.19.0"
azs = ["us-east-1a", "us-east-1b", "us-east-1c"]
name = "test-vpc"
cidr = "10.0.0.0/16"
private_subnets = ["10.0.1.0/24", "10.0.2.0/24", "10.0.3.0/24"]
public_subnets = ["10.0.101.0/24", "10.0.102.0/24", "10.0.103.0/24"]
enable_nat_gateway = true
enable_dns_hostnames = true
enable_dns_support = true
}
module "vpc_endpoints" {
source = "terraform-aws-modules/vpc/aws//modules/vpc-endpoints"
vpc_id = module.vpc.vpc_id
endpoints = {
s3 = {
service = "s3"
tags = {
Name = "s3-vpc-endpoint"
}
},
ssm = {
service = "ssm"
private_dns_enabled = true
subnet_ids = module.vpc.private_subnets
},
ssmmessages = {
service = "ssmmessages"
private_dns_enabled = true
subnet_ids = module.vpc.private_subnets
},
ec2 = {
service = "ec2"
private_dns_enabled = true
subnet_ids = module.vpc.private_subnets
},
ec2messages = {
service = "ec2messages"
private_dns_enabled = true
subnet_ids = module.vpc.private_subnets
},
}
}
From here, you could run terraform plan to see all the resources that would be
created, and terraform apply to create them.
Just the beginning
This is really just the beginning to the options available for network architecture in the cloud. You could have additional subnets that have specific designations, such as for databases or connecting to an on-prem hosted system. If you’re just getting started with networking in the cloud, though, this should be a good starting point.
